TTV Stainless steel butterfly valve 1119 + ADA/ASR pneumatic actuator
€694.23
(excl. btw)
The 1119 series stainless steel butterfly valve, equipped with either a spring return or double-acting ACTREG pneumatic actuator, features a CF8M body and polished disc. It is designed for mounting between PN10/16/25 flanges and ANSI150.
Specification
Value
Option certificate 3.1
Yes
Maximum delta P (bar)
20
Operating angle (°)
90
Shaft/stem matérial
Stainless steel 316
Adjustable limit screws
Yes
Lockable
No
ATEX compatible
Yes
DN
DN50 - 2''
Face to Face (mm)
78.0
Seat
PTFE
Body material
Stainless steel CF8M (1.4408)
ATEX protection mode
Ex c
Number of ways
2
Position
Normally closed
PS (bar)
20
Connections
Between flanges PN10/16/40 #150
Surface temperature
TX
TS max (°C)
220
TS min (°C)
-50
Pneumatic actuator type
Double acting
Butterfly valve design
Concentric
Wafer/lug
Wafer
Warranty period
2 years
CE
Risk category III
Range
TTV
Fire safe
No
If you have any questions about this product, please feel free to contact us .
Product Name
Product Number
EVAC Number
Price
Add to Cart
2125
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN50 - 2'' Double acting
264020015101
S1002073
€694.23
(excl. btw)
add to cart
2126
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN50 - 2'' Spring return
264020016103
S1002074
€771.41
(excl. btw)
add to cart
2127
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN65 - 2''1/2 Double acting
264021015102
S1002075
€856.17
(excl. btw)
add to cart
2128
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN65 - 2''1/2 Spring return
264021016104
S1002076
€912.29
(excl. btw)
add to cart
2129
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN80 - 3'' Double acting
264022015102
S1002077
€969.24
(excl. btw)
add to cart
2130
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN80 - 3'' Spring return
264022016104
S1002078
€1,082.01
(excl. btw)
add to cart
2131
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN100 - 4'' Double acting
264023015103
S1002079
€1,152.91
(excl. btw)
add to cart
2132
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN100 - 4'' Spring return
264023016104
S1002080
€1,241.14
(excl. btw)
add to cart
2133
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN125 - 5'' Double acting
264024015103
S1002081
€1,315.87
(excl. btw)
add to cart
2134
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN125 - 5'' Spring return
264024016105
S1002082
€1,516.93
(excl. btw)
add to cart
2135
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN150 - 6'' Double acting
264025015105
S1002083
€1,659.09
(excl. btw)
add to cart
2136
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN150 - 6'' Spring return
264025016107
S1002084
€2,248.90
(excl. btw)
add to cart
2137
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN200 - 8'' Double acting
264026015105
S1002085
€2,609.57
(excl. btw)
add to cart
2138
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric DN200 - 8'' Spring return
264026016107
S1002086
€3,110.27
(excl. btw)
add to cart
2139
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric Double acting DN250 - 10''
264027015107
S1002087
€3,676.09
(excl. btw)
add to cart
2140
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric Double acting DN300 - 12''
264028015107
S1002088
€4,412.93
(excl. btw)
add to cart
2141
Between flanges PN10/16/40 #150 Stainless steel CF8M (1.4408) Concentric Spring return DN300 - 12''
264028016109
S1002089
€5,940.49
(excl. btw)
add to cart
